KB-1100-E
Uniview KB-1100-E allows you to accurately control your PTZ cameras with the built-in joystick. You can pan, tilt, and zoom, taking your cameras to the next level.
Description
Uniview’s KB-1100-E allows you to quickly control your PTZ cameras using the built-in joystick. It allows for pan and tilt by moving the joystick up, down, left, and right. You can also rotate the joystick clockwise or counter-clockwise to zoom in and out – in a similar motion to turning the keys in your vehicle’s ignition. With a few minutes of practice, you’ll be controlling your PTZ camera like a pro.
This network keyboard has other functions too: Double-tapping the joystick button will immediately save a snapshot to your NVR, while the PREV and NEXT buttons allow you to switch between different cameras on the NVR’s monitor display.
This keyboard also has a web interface, similar to a Uniview NVR, in which you can login an add devices to the keyboard. For more information on how this device works, you may download the user manual.
Specification
| General | Description |
| Screen Size | 4 inches |
| Joystick | Four-dimensional joystick |
| Max Power Consumption (W) | ＜5 |
| Product Dimensions （W*H*D）（mm） | 345.00*189.82*128.16 |
| Weight (kg) | 1.2 |
| Operating Temperature | -10°C to 55°C |
| Operating Humidity | 10% to 90% RH, noncondensing |
| Other Interfaces | Description |
| Serial Port | 1*RS232 (DB9, reserved) 2*RS485 (half-duplex, reserved) |
| Console | 1*Console/RS485 shared interface (RJ45) |
| USB | 2*USB (reserved) |
| Network Interface | 1*RJ45, 10M/100M/1000M Based-T adaptive interface |
| Power | DC 12V |
| RST | 1*Reset button |
