Description
Features – LCD Splicing Display Unit
- High reliability integration design
- Built-in image splicing function
- Support special splicing compensation
- Support screen to prevent cauterizing, image flip
- Support white balance adjustment
- Support remote control and RS232 hoop control
- Support record and display working time on panel
- Support fast splicing unit ID, convenient for adjustment
- Supports double frame function
- Power delay function after power
- Stable running and low maintenance cost, supporting 24 hours continuous working
- Unit has its own customizable button, which can be customized as test pattern / burn-in and other functions
- Equipped with two HDMI input Interfaces and one HDMI loop out Interface, support video signal loop out display
Specification
| Model | MW-A55-B1 |
| Display | |
| Diagonal Size (inch) | 55″ |
| Backlight | LED (Direct type) |
| Physical Seam | 3.5 mm |
| Resolution | 1920×1080 |
| Color | 16.7M |
| Brightness | 500 cd/m2 |
| Contrast | 4000:1 |
| Response Time | 8 ms |
| Viewing Angle | Horizontal 178°, Vertical 178° |
| Interface | |
| Input Interface | 1×VGA, 1×DVI, 2×HDMI |
| Loop Interface | 1×HDMI |
| USB | 1×USB |
| Control Interface | 1×RS-232 IN, 1×RS-232 OUT, 1×IR |
| General | |
| Dimensions (W×H×D) | 1213.50mm×684.30mm×125.19mm |
| Power Supply | 100 to 240 VAC |
| Consumption | 210 W |
| Weight | 24.5 Kg |
| Operation Temperature | 0°C ~ 40 °C |
| Operating Humidity | 20%~90% (No Condensation) |
