MW-LC24 – Uniview 24-inch LED Monitor
This 24″ monitor is designed to be cost-effective and reliable for viewing your security system. It displays at a resolution of 1080p and has a viewing angle of 178°. It has one HDMI and one VGA output for connecting to an NVR or computer. It also has a VESA 100*100 mount, allowing you to attach it to a wall-mount bracket.
Description
This monitor is designed for use in CCTV applications. It displays at a resolution of 1920×1080 and has a refresh rate of 75Hz. It supports HDMI and VGA outputs, and has a thin-bezel for a sleek, modern look. It’s also energy efficient, consuming just 24 watts of power while in use. In standby mode, this drops to less than 0.5 watts.
- Monitor Size: 24-inch
- Video Input: One HDMI + One VGA
- Brightness: 250 cd/m²
- Contrast Ratio: 3000:1
Video Showcase
Specification
| Panel | Description |
| Panel Type | LED Backlight |
| Panel Size | 24″ |
| Pixel Pitch（H*V）(mm) | 0.27*0.27 |
| Resolution | 1920*1080 |
| Color Support | 16.7M |
| Brightness (cd/m²) | 250 |
| Contrast Ratio | 3000:1 |
| Refresh Rate | 75Hz |
| Response Time (ms) | 14 |
| Viewing Angle (H/V) | Horizontal 178°, Vertical 178° |
| Operation Hour | 18/7 |
| Interface | Description |
| Video Input | 1* HDMI、1*VGA |
| VESA | Description |
| VESA（mm） | 100*100 |
| Wall-mounted Thread | 4-M4 Threaded hole |
| OSD | Description |
| Multi-Language | 16 (English, French, Spanish, Portuguese, German, Italian, Dutch, Swedish, Finnish, Russian, Polish, Czech, Korean, Chinese Simplified, Chinese Traditional, Japanese) |
| General | Description |
| Input Voltage | DC 12V, 2A |
| Typical power consumption （W） | ≤24 (on) |
| Standby power consumption （W） | ≤0.5(Standby) |
| Product Dimensions （W*H*D）（mm） | 540.38*417.55*199.83 (With Pedestal) |
| Package Dimensions （W*H*D）（mm） | 601*400*145 |
| Weight（Kg） | Net Weight:3.4 Gross Weight:4.4 |
| Operation Temperature | 0°C ~ 50 °C |
| Operating Humidity | 10%~90% (No Condensation) |
| Storage Temperature | -10°C ~ 50°C |
| Storage Humidity | 10%~90% (No Condensation) |
