RE667W-R-PRO

RE667W-R-PRO

Alula Slimline Touchpad Pro, 7″ Full Colour Touchscreen, 12V DC power supply (via barrel connector or polarity-agnostic terminal), Table and Wall Mountable

Login for pricing

Category: Alarm & Intrusion Tags: Alarm Keypad, Alula

Description

Features – Alula Slimline Touchpad Pro

Vibrant 7’’ Android™ tablet display
Provides local control of security and automation functionality
Wall or table mounted
Encrypted, Connect+™ and BAT-Connect™ enabled, battery-backed Wi-Fi™ connection

Specification

Physical Specifications
Wall Dimensions Table Top Footprint Weight Pilot Hole for Screw into Wood Pilot Hole for Wall Anchor Mounting Fasteners	4.27in[10.84cm] x 7.42in[18.85cm] x 1.60[4.06cm] Deep 4.58in[11.64cm] x 7.42in[18.85cm] x 6.63[16.84cm] High 1.29lbs[585g] Ø 1/8in [3mm] Ø 3/16in [4.7mm] #6 screws & 4 wall anchors (included)
Environmental Specifications
Operating Temperature Maximum Humidity	32°F to 120°F (0°C to 49°C) 85% non-condensing relative humidity
Device Specifications
Battery Life Power Transformer Input Output Part Number Terminal Block Wire Gauge Wireless Range Screen Resolution Screen Size	4 hours 100-240vac 50/60hZ 0.5A 12VDC, 1A RE012-6 16-24 AWG ~300 feet in open air 1024 x 600 pixels 7 inches diagonally
Accessories
Wi-Fi DeviceLink	RE926RX (only needed for Connect+)
Certifications
RE667-Pro	FCC, IC, RCM
