RG-EST310-V2
This Reyee 5.8GHz wireless bridge comes with a transmitter and receiver that are pre-paired from the factory. This means no configuration is required to get these working – simply plug in the included 24V PoE injectors, point them at each other, and watch the connectivity light on the side for signal strength. You can also manage these devices from the Ruijie Reyee app but it is not a requirment.
Description
The RG-EST310-V2 is a wireless bridge that allows you to connect two locations together wirelessly. It comes with a transmitter and receiver that are paired out of the box. You can simply plug in both devices, point them at each other, and connect them to your network. These devices are for security camera use, but can also be used for internet connectivity.
You can download the Ruijie Reyee and add the wireless bridge to your account by scanning the QR code. From the app you can monitor and configure your devices. By purchasing another pair of transmitters, you can put them in point-to-multi-point mode. The RG-EST310-V2 supports one to five multipoint connectivity, allowing you to designate one device as the receiver and the others as transmitters. The beam-width is 60° horizontal and 30° vertical.
These devices must be powered using the included 24V passive PoE injectors. They do not support 48V PoE.
Videos
Highlight Features
- RG-EST310 V2 provide stable traffic transmission from 1KM away.
- Automatic pairing and automatic healing
- IP54 Weatherproof, -30℃~55℃ ensures stable operating
- Cost-effective wireless solution for elevator CCTV to avoid cable loss
Specification
| RG-EST310-V2 | |
| Wi-Fi Standards | Wi-Fi 5 (IEEE 802.11ac, Wave2) |
| Max. Wireless Speed | 5 GHz: 867Mbps |
| Weatherproof | IP54 |
| Operating Temperature | -30°C to 55°C (-22°F ~ 131°F) |
| Fixed Ports | 1 x 10/100Base-T |
| Dimensions | 147 mm x 76 mm x 37 mm |
| Certifications | CE, ROHS, UKCA, EAC |
| MIMO | 2×2, MU-MIMO |
| Antenna Gain | Directional, 10 dBi |
| Beam Width | 60° Horizontal / 30° Veritcal |
| Recommended Distance | Up to 1km |
| Transmit Power | ≤400 mW(26 dBm) (adjustable) |
| Weight | 0.35kg |
| Warranty | 3 Years |
Download
- User Manual for Reyee 5 GHz Pre-configured Wireless Bridge
- Hardware Installation Guide of RG-EST310-V2 Wireless Bridge
- Datasheet of RG-EST310-V2 Wireless Bridge
